Blustream C88CS Contractor 8x8 HDBaseT CSC Matrix - 70m (C88CS)
Blustream C88CS Contractor 8x8 HDBaseT CSC Matrix - 70m
The Blustream C88CS is an HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.2 matrix that routes 8 HDMI inputs to 8 HDBaseT™ outputs with CSC, bi-directional IR, and PoC over a single CAT cable up to 40m (1080p to 70m). It includes simultaneous HDMI/HDBaseT on output 1, video down-conversion on HDBaseT™ outputs, and a web interface for control and configuration.
Key Features
- Advanced HDBaseT™ technology for distribution of video and audio over a single CAT cable
- Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR*
- 8 x HDMI inputs can be independently routed to 8 x HDBaseT™ outputs
- Output 1 features simultaneous HDMI and HDBaseT™ output
- Video down-conversion on HDBaseT™ outputs allowing a display only capable of supporting lower video resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs
- Supports 4K 60Hz 4:4:4 UHD video up to 40m
- Extends HDMI 1080p video up to 70m
- Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
- Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
- Web interface module for control and configuration of the matrix
- Bi-directional IR supported on all HDBaseT™ outputs
- Control via front panel, IR, RS-232 and TCP/IP
- Supports PoC (Power over Cable) to power compatible HDBaseT™ receivers (RX70CS recommended)
- Supplied with Blustream IR receivers and emitters
- 3rd party drivers available for major control brands
- 1U design for 19" rack mount integration – mounting kit included
- Advanced EDID management
- HDCP 2.2 compliant
Included in the Box
- 1 x C88CS
- 1 x Rack Mounting Kit
- 1 x Remote Control
- 8 x IR Emitters
- 9 x IR Receivers
- 1 x RS-232 Control Cable
- 1 x IR Control Cable - 3.5mm-3.5mm Cable
- 1 x Quick Reference Guide
- Power Cable(s)
*For 18Gbps CSC support use RX70CS receivers.
$3,680.17
Blustream C88CS Contractor 8x8 HDBaseT CSC Matrix - 70m (C88CS)—
$3,680.17
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Blustream C88CS Contractor 8x8 HDBaseT CSC Matrix - 70m
The Blustream C88CS is an HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.2 matrix that routes 8 HDMI inputs to 8 HDBaseT™ outputs with CSC, bi-directional IR, and PoC over a single CAT cable up to 40m (1080p to 70m). It includes simultaneous HDMI/HDBaseT on output 1, video down-conversion on HDBaseT™ outputs, and a web interface for control and configuration.
Key Features
- Advanced HDBaseT™ technology for distribution of video and audio over a single CAT cable
- Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR*
- 8 x HDMI inputs can be independently routed to 8 x HDBaseT™ outputs
- Output 1 features simultaneous HDMI and HDBaseT™ output
- Video down-conversion on HDBaseT™ outputs allowing a display only capable of supporting lower video resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs
- Supports 4K 60Hz 4:4:4 UHD video up to 40m
- Extends HDMI 1080p video up to 70m
- Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
- Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
- Web interface module for control and configuration of the matrix
- Bi-directional IR supported on all HDBaseT™ outputs
- Control via front panel, IR, RS-232 and TCP/IP
- Supports PoC (Power over Cable) to power compatible HDBaseT™ receivers (RX70CS recommended)
- Supplied with Blustream IR receivers and emitters
- 3rd party drivers available for major control brands
- 1U design for 19" rack mount integration – mounting kit included
- Advanced EDID management
- HDCP 2.2 compliant
Included in the Box
- 1 x C88CS
- 1 x Rack Mounting Kit
- 1 x Remote Control
- 8 x IR Emitters
- 9 x IR Receivers
- 1 x RS-232 Control Cable
- 1 x IR Control Cable - 3.5mm-3.5mm Cable
- 1 x Quick Reference Guide
- Power Cable(s)
*For 18Gbps CSC support use RX70CS receivers.
