Blustream HEX70SL-KIT Slimline HDBaseT Extender Set 70m (HEX70SLKIT)

Blustream HEX70SL-KIT Slimline HDBaseT Extender Set 70m

The Blustream HEX70SL-KIT is a 4K HDBaseT™ extender set in a slimline chassis that delivers HDMI, Bi-directional IR, and Bi-directional PoC up to 70m. It uses advanced HDBaseT™ technology to provide uncompressed video and audio with zero latency.

Uncompressed, Zero-latency HDBaseT™ Performance

Powered by advanced HDBaseT™ technology, the Blustream HEX70SL-KIT delivers uncompressed video and audio with zero latency.

• Supports all industry standard video resolutions including VGA–WUXGA and 480i–4K.
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio.

4K UHD and Long-distance HDMI Extension

Extend HDMI over a single CAT cable for 1080p and 4K UHD applications.

• Extends HDMI 1080p up to 70m over a single CAT cable.
• Supports 4K UHD up to 40m (3840 x 2160 @ 30Hz 4:4:4, 4096 x 2160 @ 24Hz 4:4:4, and 4K @ 60Hz 4:2:0).

Installation and Control Flexibility

Includes features for control and integration in space-conscious deployments.

• Enhanced slimline chassis.
• Bi-directional IR pass-through; supplied with Blustream IR receiver and emitter.
• Supports Bi-directional PoC to power extenders from either transmitter or receiver end.
• HDCP 2.2 compliant with Smart EDID management.

Frequently Asked Questions

• What video resolutions and distances does the HEX70SL-KIT support?

  It extends HDMI 1080p up to 70m and supports 4K UHD up to 40m (3840 x 2160 @ 30Hz 4:4:4, 4096 x 2160 @ 24Hz 4:4:4, and 4K @ 60Hz 4:2:0). It also supports industry standard video resolutions from VGA–WUXGA and 480i–4K.

• Which HDMI audio formats are supported?

  It supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus, and DTS-HD Master Audio.

• Is separate power required at both ends?

  No. It supports Bi-directional PoC, allowing power from either the transmitter or receiver end.

• Is it HDCP compliant and how is EDID handled?

  Yes. The extender is HDCP 2.2 compliant and includes Smart EDID management.

• What’s included in the box?

  HEX70SL-TX, HEX70SL-RX, 12V/1A DC power supply, IR emitter, IR receiver, two mounting kits, and a Quick Reference Guide.
