Blustream RX18G Uncompressed 18Gbps HDBaseT Receiver

Blustream RX18G Uncompressed 18Gbps HDBaseT Receiver

The Blustream RX18G is an uncompressed, unconverted HDMI 2.0 4K 60Hz 4:4:4 HDBaseT receiver designed for distributing high-quality video and audio over a single CAT6A cable. It supports the latest HDR formats, delivering the ultimate in picture quality for critical viewing areas.

Uncompressed 4K 60Hz 4:4:4 with HDR

This receiver maintains full-bandwidth HDMI 2.0 signals for precise image reproduction across demanding installations.

• Supports uncompressed HDMI 2.0 18Gbps 4K 60Hz 4:4:4
• HDR support including HDR10/10+
• HDCP 2.3 support
• Advanced HDBaseT 3.0 technology

Long-distance, single-cable distribution

Video and audio are delivered over one CAT6A cable for streamlined installs. Transmission distance is subject to video format, cable type and installation environment, and a minimum of CAT6A cabling is recommended.

• Up to 100m over a single CAT6A cable
• Extends HDMI 1080p up to 150m (HDBaseT long-reach mode)
• Supports industry standard video resolutions including VGA–WUXGA and 480i–4K

Audio, control, and network integration

The RX18G includes flexible audio return and control pathways, plus pass-through networking when used within compatible Blustream systems.

• ARC (Audio Return Channel) from the connected display via HDMI or Optical (S/PDIF) when used with a compatible Blustream matrix
• Bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
• Bi-directional IR and RS-232 pass-through
• Bi-directional 1Gb Ethernet pass through when used with a compatible Blustream matrix
• PoC (Power over Cable) from compatible Blustream matrices
• Mounting kit included

Recommended system pairing

The RX18G is the recommended receiver for Blustream HMX88-18G and HMX44-18G matrix solutions.

Frequently Asked Questions

• What video formats and resolutions does the RX18G support?

  It supports uncompressed HDMI 2.0 18Gbps 4K 60Hz 4:4:4 with HDR10/10+ and HDCP 2.3. It also supports industry standard resolutions from VGA–WUXGA and 480i–4K.

• How far can the RX18G extend signals?

  It supports up to 100m over a single CAT6A cable, and up to 150m at 1080p in HDBaseT long-reach mode. Transmission distance is subject to video format, cable type and installation environment, and a minimum of CAT6A cabling is recommended.

• Does it support ARC?

  Yes. ARC is supported from the connected display via HDMI or Optical (S/PDIF) when used with a compatible Blustream matrix.

• What control and networking features are included?

  It supports bi-directional IR and RS-232 pass-through, and 1Gb Ethernet pass through when used with a compatible Blustream matrix.

• How is the RX18G powered?

  It supports PoC (Power over Cable) from compatible Blustream matrices.

• Which matrices is it recommended to use with?

  It is recommended with the Blustream HMX88-18G and HMX44-18G matrices.

• What is included in the box?

  RX18G receiver, mounting bracket set, and a quick reference guide.

Add the Blustream RX18G to your cart to build a high-performance HDBaseT system, and contact or visit Gibbys for expert, personalized advice on system compatibility, design, and setup.
