Blustream WMF51 Wireless Multiview Presentation Switch

Blustream WMF51 Wireless Multiview Presentation Switch

The Blustream WMF51 is a 4K multi-format presentation switch that brings AirPlay, Miracast, Chromecast and Blustream wireless dongles to a single HDMI output. It is designed as an ideal BYOD solution for boardroom, classroom, and huddle-space applications.

Seamless BYOD, Multi-Format Wireless Presentation

The WMF51 integrates popular wireless casting methods so users can present without cables to a single display.

• AirPlay, Miracast and Chromecast inputs to one HDMI output
• Compatible with Blustream WMF-USBC and WMF-HDMI plug-and-play wireless dongles
• Manual or automated source selection

Multi-View Collaboration and 4K Video Scaling

Enable side-by-side collaboration and clear visuals on modern displays.

• Multiview presentation with up to 4 concurrent video signals and configurable screen layouts
• In-built video scaler with output timing up to 4K 60Hz 4:4:4
• OSD control with preview function

Network-Friendly Deployment

Deploy on existing networks or run a dedicated wireless session without touching the corporate WiFi.

• Localised 2.4G/5G WiFi hotspot to host AirPlay, Miracast and Chromecast local point-to-point mode (up to 1080p)
• Dual LAN connection for integration to existing network infrastructures
• Class 0 IEEE 802.3af PoE for powering the product from a PoE switch

Flexible Control and Simple Configuration

Choose the control method that fits your room or workflow and configure from a browser.

• Control via front panel, RS-232 and TCP/IP
• Web interface module for control and configuration
• OSD control with preview and manual/auto source selection

Interactive Tools and Audio Breakout

Engage audiences and integrate with room audio.

• USB touch-back to the connected host device via WMF-USBC / WMF-HDMI dongles and Miracast
• Whiteboard and screen overlay annotation
• Audio breakout to analogue L/R

*Miracast touch-back compatibility is subject to Windows features. The USB 3.0 connection is for connectivity to an interactive display for touch-back capabilities only and does not provide full USB 3.0 bandwidth for use with VC/UC equipment.

Frequently Asked Questions

• What is the WMF51?

  It is a 4K multi-format presentation switch that accepts AirPlay, Miracast, Chromecast and Blustream wireless dongle inputs and outputs to a single HDMI display.

• Can it show multiple sources at once?

  Yes. It supports multiview presentation with up to 4 concurrent video signals and configurable screen layouts.

• What is the maximum output resolution?

  The in-built video scaler supports output timing up to 4K 60Hz 4:4:4.

• Does it provide its own WiFi?

  Yes. A localised 2.4/5G WiFi hotspot hosts AirPlay, Miracast and Chromecast local point-to-point mode up to 1080p.

• How is the unit controlled?

  Via the front panel, RS-232, or TCP/IP, with a web interface for control and configuration and OSD with preview. It supports manual or auto source selection.

• Is PoE supported?

  Yes. It features Class 0 IEEE 802.3af PoE for powering from a PoE switch.

• Does it support interactive touch-back?

  Yes. USB touch-back is supported via WMF-USBC / WMF-HDMI dongles and Miracast. Compatibility is subject to Windows features, and the USB 3.0 connection is for touch-back only (not full USB 3.0 bandwidth for VC/UC equipment).

• Is it suitable for BYOD spaces?

  Yes. It is positioned as an ideal BYOD solution for boardroom, classroom, and huddle-space applications.

Add the Blustream WMF51 to your cart to streamline BYOD presentations and collaboration, and contact or visit Gibbys Electronic Supermarket for personalized system-matching and setup advice from our experts.
