IK Multimedia Z-TONE DI Instrument Direct Box (1141127)

IK Multimedia Z-TONE DI Instrument Direct Box (1141127)

The IK Multimedia Z-TONE DI direct box brings IK’s AXE I/O sound design approach to any audio interface or live mixer. It lets players capture a processed amp/effects track and a direct track at the same time for flexible re-amping and later processing.

Record Two Tracks at Once for a More Flexible Workflow

Z-TONE DI records two simultaneous tracks: a processed track from an amplifier and effects, plus a direct track for later processing with amp simulators. As a result, players can track with real gear while keeping a second, editable DI track without recording countless takes.

• Simultaneous processed and direct recording
• Direct track ready for later processing with included AmpliTube 5 SE
• Works with any audio interface or a live mixer

Shape Input Response with Pickup Selection and Dual Circuit Topologies

The unit includes an exceptionally low-noise, high-quality instrument preamp with wide frequency response and multiple circuit topologies to match different guitars, pickups, and playing styles. It provides Active/Passive pickup selection and two distinct channels so the input path fits the source.

• Active/Passive pickup selector
• PURE channel for transparent, ultra-precise sound
• JFET Class A channel for subtle harmonic enhancement, midrange focus, and warmth

Dial In Tone and Feel with Z-TONE Variable Impedance Control

The variable impedance control adjusts from 1 MOhm to 2.2 kOhms to change how pickups respond when they hit the preamp. At maximum impedance, the sound becomes tighter, more defined, and more precise. Increase the load and the sound turns thicker and more robust.

• Z-TONE variable impedance control (1 MOhm to 2.2 kOhms)
• Wide range of tonal response from the same instrument and pickup

Clean Signal Integrity with Premium Audio Performance

Z-TONE DI preserves the natural tone of an instrument with 114 dB(A) dynamic range and an extended frequency response of 5 Hz to 30 kHz (+/- 1 dB). It keeps nuances and detail intact for high-end guitar and bass recording.

Stage-Ready Connectivity and Noise Control

Balanced and unbalanced outputs support flexible routing in studio or live rigs. The Link output splits the signal for amplifiers and pedals, and a ground switch helps eliminate noise caused by ground loops.

• Balanced XLR output with switchable ground connection
• Unbalanced 1/4" output
• Link output for splitting to amps and pedals

Extended Input Range and Power Options

An optional 20 dB pad extends the operating range, allowing use with instruments and sources beyond guitar and bass, including keyboards and synthesizers. For portability, it runs on a 9V battery, and it can also run on 48V phantom power from a mixer or interface for longer sessions.

• 20 dB pad for extended operating range
• 9V battery power for portability
• 48V phantom power operation

Included Software for Direct-Track Processing

Z-TONE DI includes AmpliTube 5 SE for Mac/PC, which provides 77 gear models for guitar and bass tone shaping. This makes it straightforward to process the recorded DI track after the performance.

Frequently Asked Questions

1. Can the unit record a processed track and a DI track at the same time? Yes. It captures a processed track from an amp and effects, plus a direct track for later processing.
2. What channels does it offer for tone shaping? It provides a PURE channel for transparent, ultra-precise sound and a JFET Class A channel that adds subtle harmonics, midrange focus, and warmth.
3. What is the impedance range of the Z-TONE control? The variable impedance control adjusts from 1 MOhm to 2.2 kOhms.
4. What output connections does it provide?
5. It offers a balanced XLR output with switchable ground connection, an unbalanced 1/4" output, and a Link output for splitting the signal to amps and pedals.
6. How can it be powered? It runs on a 9V battery for portability, or it can use 48V phantom power from a mixer or audio interface.
7. What software comes included? It includes AmpliTube 5 SE for Mac/PC with 77 gear models.

Add the IK Multimedia Z-TONE DI direct box to your cart to capture simultaneous processed and direct tracks while keeping flexible options for later tone shaping. Contact or visit Gibbys Electronic Supermarket for expert advice on choosing the right recording tools, live routing solutions, and system-matching for your setup.
